Product name：
UOTEK Ethernet to 4-port CANBUS-FD Protocol Converter
Model： UT-6504-FD
● Achieves bidirectional data transfer between CAN-bus and the network
● Supports CAN2.0, CANFD protocols
● Integrated 4 CAN-bus-FD communication interfaces, supporting communication rates from 5Kbps to 5Mbps
● Integrated 1 10M/100M Ethernet interface
● Operating Voltage: 12-36V DC
● Operating Current: ≤ 200mA@12V
● Operating Temperature: -40~+85℃
● Storage Temperature: -40~+85℃
● Operating Humidity: 5~95% (non-condensing)
● Storage Humidity: 5~95% (non-condensing)
● Isolation Voltage: 1000VDC
● ESD Protection: Level 3.
● Surge Protection: Power Port: Level 3, Network Port: Level 3
● EN 61000-4-3 CS Power 3V/m, Network 3V/m
● EN 61000-4-6 RS 10V/m
● EMI RE, CE: EN55032 classA
UT-6504-FD is a high-performance CAN-bus communication converter with integrated 4 CAN-FD interfaces and 1 network port. The converter supports interconnection between 10M/100M Ethernet networks and CAN-bus communication rates from 5Kbps to 5Mbps, further expanding the application range of CAN-bus and Ethernet. UT-6504-FD converter provides a web configuration interface, allowing users to flexibly set the operating parameters. It features an industrial-grade high-standard design with isolation between communication interfaces and the system, providing certain anti-interference and surge protection capabilities. It is widely used in industrial control and data communication systems.
